Stainless Steel 304L EFW Tubes offered at ACE ALLOYS LLP are being designed as per the national and international standard quality of raw materials. Stainless Steel 304L ERW Tubes are a practical and adaptable resistant alloy suitable, appropriate for an extensive variety of universally useful applications.
Stainless Steel 304L Round Tubes give a broadly useful stainless steel with great protection from environmental corrosion, to numerous natural and inorganic chemicals and to food and beverages. Stainless Steel 304L Square Tubes manufactured by ACE ALLOYS is containing a higher combination of chromium and lower carbon content than different varieties of types.
Stainless Steel 304L Rectangular Tubes might be considered for a wide assortment of Industrial automated or semi-automated applications where following properties are significant: Resistance to corrosion, Prevention of product contamination, Resistance to oxidation, East of fabrication. We also offer Stainless Steel 304L Electropolish tubes which are being the most versatile and commonly used stainless steels on the market.
We provide Stainless Steel 304L Welded Tubes in different sizes, thickness, standards and shapes as per tailored needs given by our clients. Take a look at our widest selection of Stainless Steel Tubes OR Contact us for your specific requirements.
| Specifications | ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790 |
| Dimensions | ASTM, ASME and API |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Wall Thickness | Sch 5s, 10s, 40s, 80s, 160, XXS |
| Outer Diameter - Seamless 304L Tubes | 3.00 mm - 219.10 mm |
| Outer Diameter - Welded 304L Tubes | 6.35 mm to 114.3 mm |
| Size | 1/2" OD - 12" OD, Guage: 25 SWG - 10 SWG |
| ERW 304L Tubes | 1/2" NB - 24" NB |
| EFW 304L Tubes | 6" NB - 100" NB |
| Form | Round, Square, Rectangular, Oval, Hydraulic etc. |
| Types | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Cut Length. |
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 304L | 1.4306/1.4307 | S30403 | SUS 304L | Z3CN18‐10 | 304S11 | 03Х18Н11 | X2CrNi18-9 / X2CrNi19-11 |
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 304L | S30403 | 304S11 | - | 1.4306 | X2CrNi19-11 | 2352 | SUS 304L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 304L | min. | - | - | - | - | - | 18.0 | - | 8.0 | - |
| max. | 0.030 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 12.0 | 0.10 | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304L | 485 | 170 | 40 | 92 | 201 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 304L | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
| 1/8" | 1/4" | 3/8" | 1/2" | 3/4" | 1" | 11/4" |
| 11/2" | 2" | 21/2" | 3" | 4" | 5" | 6" |
Request the latest Stainless Steel 304L Tubes Price List. Use the contact button below for Stainless Steel 304L Tubes Ready stock information and updated price list.
| Off-Shore Oil Drilling Companies | Power Generation | Petrochemicals | Gas Processing |
| Specialty Chemicals | Pharmaceuticals | Pharmaceutical Equipment | Chemical Equipment |
| Sea Water Equipment | Heat Exchangers | Condensers | Pulp & Paper Industry |
